Rumah ProdukStainless Steel Tubing CoiledTP 304 / 304L 1,4301 / 1,4306 Welded Stainless Steel Coil Pipa Tunggal - Inti Coiled
TP 304 / 304L 1.4301 / 1.4306 Welded Stainless Steel Coil Pipe Single - Core Coiled
TP 304 / 304L 1.4301 / 1.4306 Welded Stainless Steel Coil Pipe Single - Core Coiled TP 304 / 304L 1.4301 / 1.4306 Welded Stainless Steel Coil Pipe Single - Core Coiled
Hubungi sekarang

TP 304 / 304L 1,4301 / 1,4306 Welded Stainless Steel Coil Pipa Tunggal - Inti Coiled

Kuantitas min Order : Negotiable Harga : 5500-10000USD/TON
Kemasan rincian : Iron Kasus / Plywood Kasus Waktu pengiriman : 30 hari
Syarat-syarat pembayaran : T / T; L / C Menyediakan kemampuan : 300 ton/bulan
Tempat asal: Cina Nama merek: MTSCO
Sertifikasi: ISO 9001 & PED & AD2000 Nomor model: MTSCOSSCT40

Informasi Detail
Bahan: TP304 / 304L 1,4301 / 1,4306 Standar: ASTM A269 / A213 ASTM Standar Ganda Etc
Pengiriman Kondisi: Lembut / Hard Jenis: DILAS
Permukaan: Bright Anil / acar Fitur: flame retardant
Menyoroti:

stainless steel coil pipa

,

mulus stainless steel pipa

Deskripsi Produk

TP304 / 304L 1,4301 / 1,4306 Stainless Steel Welded Satu-core Coiled Tabung



Nomor kode pemesanan

Kode pemesanan Ukuran tabung (OD × ketebalan) Max Pressure (Bar)
NYS-1 6 × 1.0 Kerja: 180 Bar Test: 270 Bar
NYS-2 6 × 1,5
NYS-3 8 × 1,0
NYS-4 8 × 1,5
NYS-5 10 × 1.0
NYS-6 10 × 1.5
NYS-7 12 × 1.0
NYS-8 12 × 1.5

Bahan: 304.304, 316L Tebal: 0.8,1.0,1.2,1.5

Komposisi kimia

C (max) Si (max) Mn (max) P (max) S (max) cr Ni Mo Ti
TP304 / 1,4301 0.080 1.00 2.00 0,045 0.030 18,0-20,0 8,0-10,5
TP304L / 1,4307 0,035 1.00 2.00 0,045 0.030 18,0-20,0 8,0-12,0
TP316 / 1,4401 0.080 1.00 2.00 0,045 0.030 16,0-18,0 11,0-14,0 2,0-3,0
TP316L / 1,4404 0,035 1.00 2.00 0,045 0.030 16,0-18,0 10,0-14,0 2,0-3,0

Nomor kode pemesanan

ukuran tabung

(OD x Tebal x Core)

Diameter keseluruhan

(.mm)

selubung Tebal

(.mm)

Berat Bundle

(kg / M)

Max Tekanan

(Bar)

HTD-1 6 × 1,0 × 1 8 1.0 0,15

Kerja: 180Bar

Test: 270Bar

HTD-2 6 × 1,0 × 2 20 2.0 0.60
HTD-3 6 × 1,0 × 3 21 2.0 0.75
HTD-4 6 × 1,0 × 4 24 2.0 0.82
HTD-5 6 × 1.0 × 5 25 2.0 0.90
HTD-6 6 × 1,0 × 6 27 2.0 1.04
HTD-7 6 × 1,0 × 7 27 2.0 1.15
HTD-8 6 × 1,0 × 8 32 2.2 1.40
HTD-9 8 × 1,0 × 1 10 1.0 0.28
HTD-10 8 × 1,0 × 2 24 1.8 0.89
HTD-11 8 × 1,0 × 3 26 2.0 1.12
HTD-12 8 × 1,0 × 4 28 2.0 1.33
HTD-13 8 × 1.0 × 5 31 2.0 1.67
HTD-14 8 × 1,0 × 6 34 2.0 2.00
HTD-15 8 × 1,0 × 7 34 2.0 2.15
HTD-16 8 × 1,0 × 8 40 2.2 2.60
HTD-17 10 × 1.0 × 1 13 1.0 0.34
HTD-18 10 × 1.0 × 2 28 1.8 1.18
HTD-19 10 × 1.0 × 3 31 2.0 1.60
HTD-20 10 × 1.0 × 4 34 2.0 1.97
HTD-21 10 × 1.0 × 5 37 2.0 2.20
HTD-22 10 × 1.0 × 6 40 2.0 2.40
HTD-23 10 × 1.0 × 7 40 2.0 2.52
HTD-24 10 × 1.0 × 8 48 2.5 3.20
HTD-25 12 × 1.0 × 1 14 1.0 0.41
HTD-26 12 × 1.0 × 2 34 2.0 1.35
HTD-27 12 × 1.0 × 3 36 2.0 1.96
HTD-28 12 × 1.0 × 4 39 2.0 2.37
HTD-29 12 × 1.0 × 5 43 2.0 2.70
HTD-30 12 × 1.0 × 6 47 2.0 3.00
HTD-31 12 × 1.0 × 7 47 2.0 3.14
HTD-32 12 × 1.0 × 8 55 2.5 3.90



Label:

mulus stainless steel pipa

tabung stainless melingkar

stainless steel coil pipa
